# Overview

The Point Cloud tile format enables efficient streaming of massive point clouds for 3D visualization. Each point is defined by a position and by optional properties used to define its appearance, such as color and normal, as well as optional properties that define application-specific metadata.

Using 3D Tiles terminology, each point is a feature.

A Point Cloud tile is a binary blob in little endian.

# Layout

A tile is composed of a header section immediately followed by a body section. The following figure shows the Point Cloud layout (dashes indicate optional fields):

# Padding

A tile's byteLength must be aligned to an 8-byte boundary. The contained Feature Table and Batch Table must conform to their respective padding requirement.

The 28-byte header contains the following fields:

Field name	Data type	Description
`magic`	4-byte ANSI string	`"pnts"`. This can be used to identify the content as a Point Cloud tile.
`version`	`uint32`	The version of the Point Cloud format. It is currently `1`.
`byteLength`	`uint32`	The length of the entire tile, including the header, in bytes.
`featureTableJSONByteLength`	`uint32`	The length of the Feature Table JSON section in bytes.
`featureTableBinaryByteLength`	`uint32`	The length of the Feature Table binary section in bytes.
`batchTableJSONByteLength`	`uint32`	The length of the Batch Table JSON section in bytes. Zero indicates that there is no Batch Table.
`batchTableBinaryByteLength`	`uint32`	The length of the Batch Table binary section in bytes. If `batchTableJSONByteLength` is zero, this will also be zero.

The body section immediately follows the header section, and is composed of a Feature Table and Batch Table.

# Feature Table

Contains per-tile and per-point values that define where and how to render points. More information is available in the Feature Table specification.

See Property reference for the pnts feature table schema reference. The full JSON schema can be found in pnts.featureTable.schema.json.

# Semantics

# Point semantics

These semantics map to an array of feature values that define each point. The length of these arrays must be the same for all semantics and is equal to the number of points. The value for each point semantic must be a reference to the Feature Table binary body; they cannot be embedded in the Feature Table JSON header.

If a semantic has a dependency on another semantic, that semantic must be defined. If both POSITION and POSITION_QUANTIZED are defined for a point, the higher precision POSITION will be used. If both NORMAL and NORMAL_OCT16P are defined for a point, the higher precision NORMAL will be used.

Semantic	Data Type	Description	Required
`POSITION`	`float32[3]`	A 3-component array of numbers containing `x`, `y`, and `z` Cartesian coordinates for the position of the point.	✅ Yes, unless `POSITION_QUANTIZED` is defined.
`POSITION_QUANTIZED`	`uint16[3]`	A 3-component array of numbers containing `x`, `y`, and `z` in quantized Cartesian coordinates for the position of the point.	✅ Yes, unless `POSITION` is defined.
`RGBA`	`uint8[4]`	A 4-component array of values containing the `RGBA` color of the point.	🔴 No.
`RGB`	`uint8[3]`	A 3-component array of values containing the `RGB` color of the point.	🔴 No.
`RGB565`	`uint16`	A lossy compressed color format that packs the `RGB` color into 16 bits, providing 5 bits for red, 6 bits for green, and 5 bits for blue.	🔴 No.
`NORMAL`	`float32[3]`	A unit vector defining the normal of the point.	🔴 No.
`NORMAL_OCT16P`	`uint8[2]`	An oct-encoded unit vector with 16 bits of precision defining the normal of the point.	🔴 No.
`BATCH_ID`	`uint8`, `uint16` (default), or `uint32`	The `batchId` of the point that can be used to retrieve metadata from the `Batch Table`.	🔴 No.

# Global semantics

These semantics define global properties for all points.

Semantic	Data Type	Description	Required
`POINTS_LENGTH`	`uint32`	The number of points to render. The length of each array value for a point semantic should be equal to this.	✅ Yes.
`RTC_CENTER`	`float32[3]`	A 3-component array of numbers defining the center position when point positions are defined relative-to-center.	🔴 No.
`QUANTIZED_VOLUME_OFFSET`	`float32[3]`	A 3-component array of numbers defining the offset for the quantized volume.	🔴 No, unless `POSITION_QUANTIZED` is defined.
`QUANTIZED_VOLUME_SCALE`	`float32[3]`	A 3-component array of numbers defining the scale for the quantized volume.	🔴 No, unless `POSITION_QUANTIZED` is defined.
`CONSTANT_RGBA`	`uint8[4]`	A 4-component array of values defining a constant `RGBA` color for all points in the tile.	🔴 No.
`BATCH_LENGTH`	`uint32`	The number of unique `BATCH_ID` values.	🔴 No, unless `BATCH_ID` is defined.

Examples using these semantics can be found in the examples section below.

# Point positions

POSITION defines the position for a point before any tileset transforms are applied.

# Coordinate reference system (CRS)

3D Tiles local coordinate systems use a right-handed 3-axis (x, y, z) Cartesian coordinate system; that is, the cross product of x and y yields z. 3D Tiles defines the z axis as up for local Cartesian coordinate systems (also see coordinate reference system).

# RTC_CENTER

Positions may be defined relative-to-center for high-precision rendering, see Precisions, Precisions (opens new window). If defined, RTC_CENTER specifies the center position and all point positions are treated as relative to this value.

# Quantized positions

If POSITION is not defined, positions may be stored in POSITION_QUANTIZED, which defines point positions relative to the quantized volume. If neither POSITION nor POSITION_QUANTIZED is defined, the tile does not need to be rendered.

A quantized volume is defined by offset and scale to map quantized positions to a position in local space. The following figure shows a quantized volume based on offset and scale:

quantized volume

offset is stored in the global semantic QUANTIZED_VOLUME_OFFSET, and scale is stored in the global semantic QUANTIZED_VOLUME_SCALE. If those global semantics are not defined, POSITION_QUANTIZED cannot be used.

Quantized positions can be mapped to local space using the following formula:

POSITION = POSITION_QUANTIZED * QUANTIZED_VOLUME_SCALE / 65535.0 + QUANTIZED_VOLUME_OFFSET

# Point colors

If more than one color semantic is defined, the precedence order is RGBA, RGB, RGB565, then CONSTANT_RGBA. For example, if a tile's Feature Table contains both RGBA and CONSTANT_RGBA properties, the runtime would render with per-point colors using RGBA.

If no color semantics are defined, the runtime is free to color points using an application-specific default color.

In any case, 3D Tiles Styling may be used to change the final rendered color and other visual properties at runtime.

# Point normals

Per-point normals are an optional property that can help improve the visual quality of points by enabling lighting, hidden surface removal, and other rendering techniques. The normals will be transformed using the inverse transpose of the tileset transform.

# Oct-encoded normal vectors

Oct-encoding is described in A Survey of Efficient Representations of Independent Unit Vectors (opens new window). Oct-encoded values are stored in unsigned, unnormalized range ([0, 255]) and then mapped to a signed normalized range ([-1.0, 1.0]) at runtime.

# Batched points

Points that make up distinct features of the Point Cloud may be batched together using the BATCH_ID semantic. For example, the points that make up a door in a house would all be assigned the same BATCH_ID, whereas points that make up a window would be assigned a different BATCH_ID. This is useful for per-object picking and storing application-specific metadata for declarative styling and application-specific use cases such as populating a UI or issuing a REST API request on a per-object instead of per-point basis.

The BATCH_ID semantic may have a componentType of UNSIGNED_BYTE, UNSIGNED_SHORT, or UNSIGNED_INT. When componentType is not present, UNSIGNED_SHORT is used. The global semantic BATCH_LENGTH defines the number of unique batchId values, similar to the batchLength field in the Batched 3D Model header.

# Examples

This section is non-normative

These examples show how to generate JSON and binary buffers for the Feature Table.

# Positions only

This minimal example has four points on the corners of a unit length square:

var featureTableJSON = {
    POINTS_LENGTH : 4,
    POSITION : {
        byteOffset : 0
    }
};

var featureTableBinary = new Buffer(new Float32Array([
    0.0, 0.0, 0.0,
    1.0, 0.0, 0.0,
    0.0, 0.0, 1.0,
    1.0, 0.0, 1.0
]).buffer);

# Positions and colors

The following example has four points (red, green, blue, and yellow) above the globe. Their positions are defined relative to center:

var featureTableJSON = {
    POINTS_LENGTH : 4,
    RTC_CENTER : [1215013.8, -4736316.7, 4081608.4],
    POSITION : {
        byteOffset : 0
    },
    RGB : {
        byteOffset : 48
    }
};

var positionBinary = new Buffer(new Float32Array([
    0.0, 0.0, 0.0,
    1.0, 0.0, 0.0,
    0.0, 0.0, 1.0,
    1.0, 0.0, 1.0
]).buffer);

var colorBinary = new Buffer(new Uint8Array([
    255, 0, 0,
    0, 255, 0,
    0, 0, 255,
    255, 255, 0,
]).buffer);

var featureTableBinary = Buffer.concat([positionBinary, colorBinary]);

# Quantized positions and oct-encoded normals

In this example, the four points will have normals pointing up [0.0, 1.0, 0.0] in oct-encoded format, and they will be placed on the corners of a quantized volume that spans from -250.0 to 250.0 units in the x and z directions:

var featureTableJSON = {
    POINTS_LENGTH : 4,
    QUANTIZED_VOLUME_OFFSET : [-250.0, 0.0, -250.0],
    QUANTIZED_VOLUME_SCALE : [500.0, 0.0, 500.0],
    POSITION_QUANTIZED : {
        byteOffset : 0
    },
    NORMAL_OCT16P : {
        byteOffset : 24
    }
};

var positionQuantizedBinary = new Buffer(new Uint16Array([
    0, 0, 0,
    65535, 0, 0,
    0, 0, 65535,
    65535, 0, 65535
]).buffer);

var normalOct16PBinary = new Buffer(new Uint8Array([
    128, 255,
    128, 255,
    128, 255,
    128, 255
]).buffer);

var featureTableBinary = Buffer.concat([positionQuantizedBinary, normalOct16PBinary]);

# Batched points

In this example, the first two points have a batchId of 0, and the next two points have a batchId of 1. Note that the Batch Table only has two names:

var featureTableJSON = {
    POINTS_LENGTH : 4,
    BATCH_LENGTH : 2,
    POSITION : {
        byteOffset : 0
    },
    BATCH_ID : {
        byteOffset : 48,
        componentType : "UNSIGNED_BYTE"
    }
};

var positionBinary = new Buffer(new Float32Array([
    0.0, 0.0, 0.0,
    1.0, 0.0, 0.0,
    0.0, 0.0, 1.0,
    1.0, 0.0, 1.0
]).buffer);

var batchIdBinary = new Buffer(new Uint8Array([
    0,
    0,
    1,
    1
]).buffer);

var featureTableBinary = Buffer.concat([positionBinary, batchIdBinary]);

var batchTableJSON = {
    names : ['object1', 'object2']
};

# Per-point properties

In this example, each of the 4 points will have metadata stored in the Batch Table JSON and binary.

var featureTableJSON = {
    POINTS_LENGTH : 4,
    POSITION : {
        byteOffset : 0
    }
};

var featureTableBinary = new Buffer(new Float32Array([
    0.0, 0.0, 0.0,
    1.0, 0.0, 0.0,
    0.0, 0.0, 1.0,
    1.0, 0.0, 1.0
]).buffer);

var batchTableJSON = {
    names : ['point1', 'point2', 'point3', 'point4']
};

# Batch Table

The Batch Table contains application-specific metadata, indexable by batchId, that can be used for declarative styling and application-specific use cases such as populating a UI or issuing a REST API request.

If the BATCH_ID semantic is defined, the Batch Table stores metadata for each batchId, and the length of the Batch Table arrays will equal BATCH_LENGTH.
If the BATCH_ID semantic is not defined, then the Batch Table stores per-point metadata, and the length of the Batch Table arrays will equal POINTS_LENGTH.

See the Batch Table reference for more information.

# Extensions

The following extensions can be applied to a Point Cloud tile.

3DTILES_draco_point_compression

# File extension and MIME type

Point cloud tiles use the .pnts extension and application/octet-stream MIME type.

An explicit file extension is optional. Valid implementations may ignore it and identify a content's format by the magic field in its header.

# Property reference

Point Cloud Feature Table

# Point Cloud Feature Table

A set of Point Cloud semantics that contains values defining the position and appearance properties for points in a tile.

Properties

	Type	Description	Required
extensions	`object`	Dictionary object with extension-specific objects.	No
extras	`any`	Application-specific data.	No
POSITION	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
POSITION_QUANTIZED	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
RGBA	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
RGB	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
RGB565	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
NORMAL	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
NORMAL_OCT16P	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
BATCH_ID	`object`	A `BinaryBodyReference` object defining the reference to a section of the binary body where the property values are stored. See the corresponding property semantic in Semantics.	No
POINTS_LENGTH	`object`, `number` `[1]`, `number`	A `GlobalPropertyInteger` object defining an integer property for all points. See the corresponding property semantic in Semantics.	✅ Yes
RTC_CENTER	`object`, `number` `[3]`	A `GlobalPropertyCartesian3` object defining a 3-component numeric property for all points. See the corresponding property semantic in Semantics.	No
QUANTIZED_VOLUME_OFFSET	`object`, `number` `[3]`	A `GlobalPropertyCartesian3` object defining a 3-component numeric property for all points. See the corresponding property semantic in Semantics.	No
QUANTIZED_VOLUME_SCALE	`object`, `number` `[3]`	A `GlobalPropertyCartesian3` object defining a 3-component numeric property for all points. See the corresponding property semantic in Semantics.	No
CONSTANT_RGBA	`object`, `number` `[4]`	A `GlobalPropertyCartesian4` object defining a 4-component numeric property for all points. See the corresponding property semantic in Semantics.	No
BATCH_LENGTH	`object`, `number` `[1]`, `number`	A `GlobalPropertyInteger` object defining an integer property for all points. See the corresponding property semantic in Semantics.	No

Additional properties are allowed.

Type of each property: Property

# PointCloudFeatureTable.extensions

Dictionary object with extension-specific objects.

Type: object
Required: No
Type of each property: Extension
